TSC2011HYDT STMicroelectronics Current Sensing Amplifier Single 8-Pin SO-8
- N° de stock RS:
- 234-8913
- Référence fabricant:
- TSC2011HYDT
- Fabricant:
- STMicroelectronics
Bénéficiez d'une remise sur les achats en gros
Ajoutez 20 de plus pour économiser 2%
Consulter les options de prix de grosSous-total (1 paquet de 2 unités)*
6,53 €
(TVA exclue)
7,90 €
(TVA incluse)
Frais de livraison offerts pour toute commande de plus de 90,00 €
En stock
- Plus 2 498 unité(s) expédiée(s) à partir du 11 novembre 2026
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Unité | Prix par unité | le paquet* | Économie |
|---|---|---|---|
| 2 - 18 | 3,265 € | 6,53 € | - |
| 20 - 98 | 3,18 € | 6,36 € | 2% |
| 100 - 198 | 3,11 € | 6,22 € | 4% |
| 200 + | 2,91 € | 5,82 € | 10% |
*Prix donné à titre indicatif
- N° de stock RS:
- 234-8913
- Référence fabricant:
- TSC2011HYDT
- Fabricant:
- STMicroelectronics
Spécifications
Documentation technique
Législations et de normes
Détails du produit
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout | Attribut | Valeur |
|---|---|---|
| Marque | STMicroelectronics | |
| Product Type | Current Sensing Amplifier | |
| Power Supply Type | Single | |
| Minimum Supply Voltage | 2.7V | |
| Maximum Supply Voltage | 5.5V | |
| CMRR - Common Mode Rejection Ratio | 80dB | |
| Number of Channels | 1 | |
| Supply Current | 5mA | |
| Mount Type | Surface | |
| Package Type | SO-8 | |
| Pin Count | 8 | |
| GBP - Gain Bandwidth Product | 750kHz | |
| Minimum Operating Temperature | -40°C | |
| Standards/Approvals | No | |
| Length | 5mm | |
| Height | 1.75mm | |
| Series | TSC2011 | |
| Automotive Standard | AEC-Q100 | |
| Maximum Operating Temperature | 150°C | |
| Sélectionner tout | ||
|---|---|---|
Marque STMicroelectronics | ||
Product Type Current Sensing Amplifier | ||
Power Supply Type Single | ||
Minimum Supply Voltage 2.7V | ||
Maximum Supply Voltage 5.5V | ||
CMRR - Common Mode Rejection Ratio 80dB | ||
Number of Channels 1 | ||
Supply Current 5mA | ||
Mount Type Surface | ||
Package Type SO-8 | ||
Pin Count 8 | ||
GBP - Gain Bandwidth Product 750kHz | ||
Minimum Operating Temperature -40°C | ||
Standards/Approvals No | ||
Length 5mm | ||
Height 1.75mm | ||
Series TSC2011 | ||
Automotive Standard AEC-Q100 | ||
Maximum Operating Temperature 150°C | ||
The STMicroelectronics precision bidirectional current sense amplifiers can sense the current thanks to a shunt resistor over a wide range of common mode voltages, from - 20 to + 70 V, whatever the supply voltage is. It is able to sense very low drop voltages as low as 10 mV full scale minimizing the measurement error.
Offset voltage ± 200 μV maximum
2.7 to 5.5 V supply voltage
Gain error 0.3% maximum
Offset drift 5 μV/°C maximum
