RS PRO 1 Output 1000 VA Chassis Mount Transformer, 230 V ac, ASNZS 61558.1, IECBSEN 615586, RoHS, CE, IECBSEN 615581,

Voir la catégorie
Offre groupée disponible

Sous-total (1 unité)*

175,17 €

(TVA exclue)

211,96 €

(TVA incluse)

Add to Basket
sélectionner ou taper la quantité
En stock
  • 10 unité(s) prête(s) à être expédiée(s) d'un autre centre de distribution
Besoin de plus? Cliquez sur " Vérifier les dates de livraison " pour plus de détails
Unité
Prix par unité
1 - 24175,17 €
25 +160,63 €

*Prix donné à titre indicatif

N° de stock RS:
504-173
Fabricant:
RS PRO
Recherchez des produits similaires en sélectionnant un ou plusieurs attributs.
Sélectionner tout

Marque

RS PRO

Primary Voltage

415 V ac

Product Type

Chassis Mount Transformer

Secondary Voltage

230 V ac

Power

1000VA

Fixing Hole Diameter

6.5mm

Minimum Operating Temperature

-30°C

Maximum Operating Temperature

130°C

Minimum Operating Frequency

50Hz

Length

150mm

Weight

5kg

Depth

110mm

Standards/Approvals

ASNZS 61558.1, IECBSEN 615586, RoHS, CE, IECBSEN 615581, ASNZS 61558..6

Maximum Operating Frequency

60Hz

Pays d'origine :
PL

RS PRO Panel Isolation Transformer, Primary voltage 230, 245, 400, 415 V ac, Secondary voltage ± 12 V ac


It has been over 100 years since the introduction of the first commercial Transformer when the mass production began. Since then, many additional modifications we developed to support various applications, such as electromagnetic, relays, pumps or heating elements.

.

The functionality of the Isolation Transformer has a concept to provide galvanic isolation between the AC power lines (mains) and the connected device, meaning no a DC can cross between the windings.

Today, we are proudly introducing our own branded RS PRO Isolation Transformer with a screw connector for multiple input and brackets for screw fixation. The exceptional isolating property and safety of our Transformer provide step up or step down of line (mains) voltages while reducing the noise coming from the primary to secondary or opposite.

The Isolation Transformers supports different types of equipment, from testing power-related devices to medical isolation equipment. However, they must meet rigorous electrical requirements to make sure no leakage current is in place.

Features and Benefits


  • 100% electrical and flash tested following BS EN 61558-1 regulations

  • Our Transformer provides high-quality safety and isolating properties for use in control circuits and general applications

  • Exceptional low loss noise laminations characterising our Isolation Transformer

  • Thanks to the dual standard primary winding 230/400 V ac with +15 V tap creates input flexibility to your equipment

  • The Transformer has an earth terminal provided whereas the dual secondaries are centre tapped

  • The Isolation Transformer has reliable protection against humidity and rusting thanks to varnish impregnation

  • The Transformer is fully shrouded cage clamp terminal with the voltage markings

  • All the crucial technical information is available on the permanent label attached

  • The Isolation Transformer provides high efficiency with a low regulation design

    • Applications


    The Transformer with isolating properties has an association with the following applications:

  • Medical industry

  • Testing power devices

  • where transfer power between two circuits is mandatory

    • Why RS PRO?


    RS PRO is our own-brand range of great-value products. Each part of every RS PRO product is stringently tested against demanding industry standards. We give it our seal of approval only when we're confident of exceptional quality. That's why RS PRO is trusted by engineers worldwide.

    Laminated
