- N° de stock RS:
- 122-677
- Référence fabricant:
- L07-200-MPQG
- Fabricant:
- Norgren
2 En stock, livraison sous 1 jour(s) (stock Europe)
6 En stock, livraison sous 3 à 5 jours (stock Europe)
Ajouté
Prix la pièce
79,49 €
(TVA exclue)
96,18 €
(TVA incluse)
Unité | Prix par unité |
1 - 4 | 79,49 € |
5 - 9 | 77,02 € |
10 + | 74,56 € |
- N° de stock RS:
- 122-677
- Référence fabricant:
- L07-200-MPQG
- Fabricant:
- Norgren
Documentation technique
Législations et de normes
Statut RoHS non applicable
- Pays d'origine :
- MX
Détails du produit
IMI Norgren Pneumatic Air Lubricator, 10 Bar Maximum Operating Pressure, 6.7L/s Flow Rate - L07 Series - L07-200-MPQG
Keep your pneumatic equipment running smoothly with this air lubricator from IMI Norgren. It has a sight-feed dome that safely stores the oil lubricant and feeds it through your system according to your settings. The dome has all-round visibility so it's easy to monitor the drip-rate. A flow rate capacity of 6.7L/s (litres per second) means you can use this lubricator with confidence in high-flow applications. It comes with a transparent bowl that collects the filtration to prevent overflow.
Features & Benefits
• Polycarbonate bowl is resistant to heavy impacts for use in demanding industrial settings
• Both panel and bracket mounting options for convenience
• Maximum operating pressure of 10 bar for use in high-pressure applications
• Durable zinc-alloy body to withstand harsh conditions
• Both panel and bracket mounting options for convenience
• Maximum operating pressure of 10 bar for use in high-pressure applications
• Durable zinc-alloy body to withstand harsh conditions
Applications
• Food and beverage production
• Chemical plants
• Medical technology
• Marine industry
• Chemical plants
• Medical technology
• Marine industry
How does a micro-fog lubricator work?
A micro-fog lubricator like this one works by releasing the oil lubrication in tiny particles as small as 2 microns. These mist-like droplets are then passed into the pneumatic components in a thin film that's suitable for complex systems.
Spécifications
Attribut | Valeur |
---|---|
Port Connection | G 1/4 |
Port Connection Thread Size | 1/4 in |
Manufacturer Series | L07 |
Typical Flow Rate | 6.7L/s |
Port Connection Thread Standard | G |
Maximum Operating Pressure | 10 bar |
Maximum Operating Temperature | +50°C |
Minimum Operating Temperature | -20°C |
