Schneider Electric ClimaSys CV Series Filter Fan, 230 V, AC Operation, 65 m³/h @ 50 Hz Filtered, 170m³/h Unimpeded,
- N° de stock RS:
- 177-9016
- Référence fabricant:
- NSYCVF65M230PF
- Fabricant:
- Schneider Electric
2 En stock, livraison sous 1 jour(s) (stock Europe)
15 En stock, livraison sous 3 à 5 jours (stock Europe)
Ajouté
Prix la pièce
48,97 €
(TVA exclue)
59,25 €
(TVA incluse)
Unité | Prix par unité |
1 + | 48,97 € |
Better World
Notre gamme de produits Better World vous facilite l'accès à des produits plus durables et plus fiables. Cliquez ici pour en savoir plus.
- N° de stock RS:
- 177-9016
- Référence fabricant:
- NSYCVF65M230PF
- Fabricant:
- Schneider Electric
Documentation technique
Législations et de normes
Détails du produit
Schneider Electric Filter Fan
The Schneider Electric ClimaSys CV series filter fan is designed with optimised fins and blades to enable maximum airflow and low energy consumption. It is designed to maximise filter surface area, thus capturing and filtering more air. The flat structure minimises the protrusion of the fan from the surface of the enclosure wall. This new generation filter fan prevents dust and other contaminants from entering the enclosure through any unsealed opening. This efficient and economical filter fan enables optimum airflow and removes unwanted heat from the enclosure and maintains a safe temperature within the enclosure. All the Schneider Electric products are designed to sustain a long life. This fan is one of the many available configurations for indoor as well as outdoor use.
Features and Benefits
• Efficient filter power
• Long lasting
• Low energy consumption
• Low noise
• Space saver
• With outlet grille
• Filtered air flow is 65m³/h
• Long lasting
• Low energy consumption
• Low noise
• Space saver
• With outlet grille
• Filtered air flow is 65m³/h
Applications
• Factory
• Kitchen
• Steam room and bathroom
• Kitchen
• Steam room and bathroom
Certifications
• IP20 rating
• UL approved
• UL approved
Spécifications
Attribut | Valeur |
---|---|
Unimpeded Air Flow | 170m³/h |
Filtered Air Flow | 65 m³/h @ 50 Hz |
AC or DC Operation | AC |
Face Dimensions | 124 x 124mm |
Installation Depth | 55mm |
Supply Voltage | 230 V |
Face Height | 124mm |
Face Width | 124mm |
IP Rating | IP20 |
Better World Verification | Green Premium |
Better World Product | Yes |
Series | ClimaSys CV |
Special Features | Protective Grille on the Front & Rear Surfaces |
